DLA 09009 Ultra Low ESR Module

Features & Benefits

Capacitance ranging from 9.4µF to 1,980µF; Voltage range from 6 to 50V
Ideal for reducing board space layout where multiple tantalum components are used in parallel
Additional module ratings and form factors may be available upon request

Typical Applications

Military
Avionics
Space

The DLA 09009 Series tantalum module represents the highest packing density for large capacitance / voltage ratings available in surface mount tantalum. These modules feature stacked assemblies of CWR29 style capacitors which provide ultra low ESR and utilize established reliability capacitors (Weibull Grade voltage conditioning) in accordance with MIL-PRF-55365. Ideal for reducing board space layout where multiple tantalum components are used in parallel and additional module ratings and form factors may be available upon request.

Datasheet / Catalog
