TRM Professional Multianode Series

Features & Benefits

Improved Reliability – 0.5%/1khrs (Twice Better than Standard)
DCL Reduced by 25% to 0.0075 CV
Robust Against Higher Thermo-mechanical Stresses During Assembly Process
Multi-anode Construction
Super Low ESR
100% Surge Current Tested
CV range 4.7-1500μF / 2.5-50V
“Mirror” Construction Used with D Case Capacitors Reduces ESL to Half
Automotive, Industrial and Other Higher End Applications

Typical Applications

Automotive, Avionics and Industrial High Power DC/DC Converters

TRM series capacitors are designed for high-end commercial applications with long operating life expectancies. The low ESR value of these capacitors is achieved through their multi-anode construction, which provides larger surge current capability within the same case size. Temperature cycling, double burn-in time (aging), and exception limit controls in place ensures superior quality and enhanced reliability levels within the commercial product portfolio.
