Hybrid 3dB – DB0402 90° Couplers

Features & Benefits

Inherent Low Profile
Self Alignment during Reflow
Excellent Solderability
Low Parasitics
Better Heat Dissipation

Typical Applications

4G / 5G LTE
Base Stations
Automotive
Industrial
Mobile communications
Satellite TV receivers
GPS
Vehicle location systems
Wireless LAN’s

The ITF 3dB LGA Coupler is based on thin-film multilayer technology. The technology provides a miniature part with excellent high frequency performance and rugged construction for reliable automatic assembly. The ITF Coupler is offered in a variety frequency bands compatible with various types of high frequency wireless systems.
